| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HAIBAO |
| Model Number: | F160 |
| Minimum Order Quantity: | 10 |
| Price: | PRICE NEGOTIABLE |
| Packaging Details: | 55 units/40HQ |
| Delivery Time: | Thirty days |
| Payment Terms: | T/T |
| Supply Ability: | 10000 UNITS/MONTH |
| Outline Size: | 3100*180*1370mm | Carriage Size: | 1600*1100mm |
|---|---|---|---|
| Car Door Structure: | Can Be Oped On All Sides |
| 型号配置详情 Model configuration details |
名称 Name | F160 | 后减震系统 Rear damping system | 板簧减震 Shock absorption of leaf spring | |
| 外形尺寸 Outline size | 3100*180*1370mm | 前制动系统 Front brake system | 鼓刹 Drum brake |
||
| 车厢尺寸 Carriage size | 1600*1100mm | 后制动系统 Rear brake system | 鼓刹 Drum brake |
||
| 轴距 Wheelbase | 2030mm | 轮毂 Hub | 钢轮 Steel wheel | ||
| 轮距 Wheel distance | 960mm | 前轮胎尺寸 Front tire size | 3.75-12内外胎 3.75-12 Internal and external tire | ||
| 车门结构 Car door structure | 四面可开 Can be oped on all sides | 后轮胎尺寸 Rear tire size | 4.00-12内外胎 4.00-12 Internal and external tire | ||
| 乘客人数 Number of cab passengers (persons) | 1 | 前大灯 Headlight | LED灯珠凸镜大灯远近光 LED lamp bead convex mirror headlamp / near and far light | ||
| 额定载重 Rated cargo weight (kg) | 500 | 仪表 Meter | 液晶显示屏 LCD screen | ||
| 最小离地间隙 Minimum ground clearance | ≥20CM(no-load) | 反光镜 Rearview mirror | 手动折叠 Manual fold | ||
| 控制器 Controller | 60V-72V24管 60V-72V24 tube |
座椅/靠背 Seat / backrest | 高档座椅 High end seats |
||
| 后桥总成 Rear axle assembly | 一体后桥 Integrated rear axle | 前保险杠 Front bumper | 黑色碳钢 ●Black carbon steel | ||
| 转向系统 Steering system | 把手 handlebar | 喇叭 Horn | 前双喇叭 Front dual horn | ||
| 前减震系统 Front damping system | 铝筒液压减震 Aluminum cylinder hydraulic shock absorber | 最大时速Max. speed | 38km/h | ||
| 最大续航 Maximum range | 110km | 电机功率Motor Power | 1500WD | ||
