Product Details
Place of Origin: CHINA
Brand Name: HAIBAO
Model Number: F180
Payment & Shipping Terms
Minimum Order Quantity: 10
Price: PRICE NEGOTIABLE
Packaging Details: 30 units/40HQ
Delivery Time: Thirty days
Payment Terms: T/T
Supply Ability: 10000 UNITS/MONTH
Motor: |
1500WD |
Vehicle Size: |
3330*1380*1360mm |
Max. Speed: |
35-40km/h |
Controller: |
60V-72V 24 Tubes |
Rear Cargo Box Size: |
1800*1300mm |
Motor: |
1500WD |
Vehicle Size: |
3330*1380*1360mm |
Max. Speed: |
35-40km/h |
Controller: |
60V-72V 24 Tubes |
Rear Cargo Box Size: |
1800*1300mm |
Basic Specification |
Product name | F180 | |||
| Motor | 1500WD | ||||
| Vehicle size | 3330*1380*1360mm | ||||
| Rear cargo box size | 1800*1300mm | ||||
| Battery Box Dimensions | 700*700*300mm | ||||
| Number of doors | 3 | ||||
| Rated crew | 1 | ||||
| Curb weight | 322kg | ||||
| Rated load capacity | ≤578kg | ||||
| Max. speed | 35-40km/h | ||||
| Battery | Maximum installable PbAc(72V100AH ) | ||||
| Max. range | 100-120km | ||||
| Wheel distance | 1150mm | ||||
| Wheelbase | 2190mm | ||||
| Charging time | 6-8h | ||||
| Distance from ground | 220mm | ||||
Suspension system |
Front axle assembly | — | |||
| Rear axle assembly | Integrated Rear Axle | ||||
Damping system |
Front shock absorption system | Aluminum Tube Hydraulic Shock Absorption | |||
| Rear shock absorption system | Leaf Spring Shock Absorption | ||||
Other configurations |
Steering system | Handlebar | |||
| Controller | 60V-72V 24 Tubes | ||||
| Front & Rear brake system | Drum brake | ||||
| Parking method | Independent handbrake | ||||
| Wheel hub | Steel Wheel | ||||
| Tire | Front 4.00-12 Inner and Outer Tires, Rear 4.50-12 Inner and Outer Tires | ||||
| Headlight | LED | ||||
| Meter | LCD | ||||
| Rearview mirror | Manual folding | ||||
| Seat | Ordinary leather seats | ||||
| Sunroof | — | ||||
| Independent fan | — | ||||
| Electric heater | — | ||||
| Anti-theft alarm | — | ||||
| Contral locking | — | ||||
| Child lock | — | ||||
| Headlight | LED | ||||
| License plane light | ● | ||||
| Front fog lights | — | ||||
| Rear fog light | ● | ||||
| High brake light | ● | ||||
| Spotlight | — | ||||
| Meter | LCD screen | ||||
| Radio | — | ||||
| (USB)multimedia interface | — | ||||
| Bluetooth | — | ||||
| Mobile phone charging (USB) | — | ||||
| Reversing image | — | ||||
| Rearview mirror | Manual folding | ||||
| Seat belt | — | ||||
| Sun visor | — | ||||
| Foot pad materia | — | ||||
| Front brick | — | ||||
| Wiper | — | ||||
| Front bumper | ● | ||||
| Rear bumper | — | ||||
| Luggage rack | — | ||||
| Slope descent control | — | ||||
