| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HAIBAO |
| Model Number: | B05 |
| Minimum Order Quantity: | 10 |
| Price: | PRICE NEGOTIABLE |
| Packaging Details: | 40 units/40HQ |
| Delivery Time: | Thirty days |
| Payment Terms: | T/T |
| Supply Ability: | 10000 UNITS/MONTH |
| Outline Size: | 3530*1420*1860mm | Rear Brake System: | Oil Brake |
|---|---|---|---|
| Hub: | Steel Wheel | Internal Dimensions Of The Container: | 2120*1265*385mm |
| Carriage Size: | 2200*1420mm | Controller System: | 3kW36tube Controller |
| 型号配置详情Model configuration details |
名称Name | B05(重载) | 后刹车系统 Rear brake system |
油刹 oil brake |
|
| 整车尺寸Outline size | 3530*1420*1860mm | 轮毂Hub | 钢轮 Steel wheel |
||
| 车厢尺寸Carriage size | 2200*1420mm | 前轮胎尺寸Front tire size | 13*5.2互换13*5.2interchange | ||
| 车箱内部尺寸Internal dimensions of the container | 2120*1265*385mm | 后轮胎尺寸Rear tire size | 13*5.2互换13*5.2interchange | ||
| 轴距wheel base | 2250mm | 轮距tread | 1180mm | ||
| 乘客人数(人)Number of cab passengers (persons) | 1 | 车头灯Headlight | LED 灯珠凸镜大灯/远近光LED lamp bead convex mirror headlamp / high and low beam | ||
| 额定货物重量(千克)Rated cargo weight (kg) | 2000 | 仪表盘Meter | LCD屏幕 LCD screen |
||
| 最小离地间隙Minimum ground clearance | ≥19CM(no-load) | 后视镜Rearview mirror | 手动折叠 Manual fold |
||
| 控制系统Controller system | 3千瓦36管控制器 3kW36tube controller |
座椅/靠背Seat / backrest | 高级皮革,泡沫棉座椅 High grade leather, foam cotton seat |
||
| 后桥总成Rear axle assembly | 70桥管250锅加重型油刹变档悬浮后桥 70 axle tube 250 pot weighted oil brake shift suspension rear axle |
前保险杠Front bumper | 大号 黑色碳钢 Enlarge Black carbon steel |
||
| 转向系统Steering system | 把式 handlebar |
喇叭Horn | 前置双喇叭 Front dual horn |
||
| 前减震系统Front damping system | 60外簧直筒减震 60 Outer Spring Straight Shock Absorber |
防滑坡Anti slide slope | ● | ||
| 后减震系统Rear damping system | 60外簧直筒减震60 Outer Spring Straight Shock Absorber | 电机功率Motor | 72V3000W大泰永磁同步电机72V3000W Daitai permanent magnet synchronous motor | ||
| 前制动系统Front brake system | 毂刹 Hub brake |
Max speed | 30km/h | ||
| 额定载重Rated load | 1500kg | Max Range | 90km | ||
