Shandong Bus New Energy Vehicle Co., Ltd. admin@haibaoev.com 86--15857925555
Product Details
Place of Origin: CHINA
Brand Name: HAIBAO
Model Number: L1-D
Payment & Shipping Terms
Minimum Order Quantity: 250
Price: PRICE NEGOTIABLE
Packaging Details: 250 units/40HQ
Delivery Time: Thirty days
Payment Terms: T/T
Supply Ability: 10000 UNITS/MONTH
Motor Power: |
350W |
Vehicle Size: |
1450*300*750mm |
Rated Load Capacity: |
150kg |
Controller: |
Zhengxuan Wave 6 Tube Controller |
Max. Range: |
60km |
Motor Power: |
350W |
Vehicle Size: |
1450*300*750mm |
Rated Load Capacity: |
150kg |
Controller: |
Zhengxuan Wave 6 Tube Controller |
Max. Range: |
60km |
Basic Specification |
Product name | L1-D | ||
| Motor power | 350W | |||
| Vehicle size | 1450*300*750mm | |||
| Curb weight | 20-30kg | |||
| Wheelbase | 1100mm | |||
| Rated load capacity | 150kg | |||
| Max. speed | 35-40km/h | |||
| Controller | Zhengxuan Wave 6 tube controller | |||
| Transfer handle/Horn | High end/waterproof | |||
| Battery | Lead acid battery 48V20AH | |||
| Max. range | 60km | |||
| Battery compartment ground clearance | 17mm | |||
| Charging time | 6-8h | |||
| Damping system | shock absorption system | Front hydraulic shock absorber, rear high elastic shock absorber | ||
| Climbing angel | 20° | |||
| Front & Rear brake system | Front drum brake | |||
| Wheel hub | 14 inch | |||
| Tire | 14-2.5 | |||
| Headlight | High and low beams headlights | |||
| Meter | Digital display instrument | |||
| Rearview mirror | ● | |||
| Turn signal | ● | |||
| Tail light | ● | |||
| Rear brake light | ● | |||
| Seat | High elastic saddle sponge backrest | |||
| Side support | ● | |||
| Color | Optional | |||
